505 ARG
McMichael Radio Ltd.; Slough
- Country
- Great Britain (UK)
- Manufacturer / Brand
- McMichael Radio Ltd.; Slough
- Year
- 1950
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 141782
-
- alternative name: McMichael, Leslie
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superheterodyne (common); ZF/IF 470 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 200-250 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- from Radiomuseum.org
- Model: 505 ARG - McMichael Radio Ltd.; Slough
- Notes
- Radiogram fitted with Garrard RC72, 3 speed record changer. Similar chassis to model 501 except it has an additional valve L77 to provide extra amplification for the pick-up.
- Price in first year of sale
- 69.00 GBP
- Source of data
- -- Schematic
- Literature/Schematics (1)
- Radio And Television Servicing books (R&TVS) (Vol I, Pre 1953. Page 324. Trader Sheet 970.)
- Author
- Model page created by Keith Staines. See "Data change" for further contributors.
