- Country
- Great Britain (UK)
- Manufacturer / Brand
- McMichael Radio Ltd.; Slough
- Year
- 1954
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 303061
-
- alternative name: McMichael, Leslie
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 18
- Valves / Tubes
- PCC84 PCF80 EF80 EF80 EF80 PL83 LN309 ECL80 PL81 EY51 PY81 EF80 EF80 ECL80 EB91 ECL80 PL82 MW36-24
- Main principle
- Superheterodyne (common)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- AC/DC-set / 200-250 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: C54A - McMichael Radio Ltd.; Slough
- Shape
- Console with any shape - in general
- Notes
-
Console TV set with a 14 inch black and white 405 line CRT. 12 channel VHF GB band I/III tuner.
- Literature/Schematics (1)
- Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1183/T67)
- Author
- Model page created by Howard Craven. See "Data change" for further contributors.
