• Country
• United States of America (USA)

• Manufacturer / Brand
• McMurdo Silver, Inc.(pre WW2); Chicago

• Year
• 1936 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 320310

• Number of Tubes
• 20

• Valves / Tubes
• 6K7 6K7 6L7 6J7 6G5 6K7 6K7 6K7 6Q7 6K7 6H6 6C5 6C5 6L6 6L6 6L7 6C5 6H6 5Z3 5Z3

• Main principle
• Superhet with RF-stage

• Wave bands
• Broadcast, Long Wave and 2 x Short Wave.

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 110 Volt

• Loudspeaker
• Ø 18 inch = 45.7 cm

• Power out
• 17 W (undistorted)

• Material
• Various materials

• from Radiomuseum.org
• Model: Masterpiece V Norwich - McMurdo Silver, Inc.pre WW2;

• Shape
• Console, Lowboy (legs < 50 %).

• Dimensions (WHD)
• 730 x 1230 x 480 mm / 28.7 x 48.4 x 18.9 inch

• Author
• Model page created by Carlos Insa Gracia. See "Data change" for further contributors.

• Other Models

• Here you find 40 models, 38 with images and 8 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from McMurdo Silver, Inc.(pre WW2); Chicago
