Reportermagnetofon R 5
Mechanikai Laboratórium (ML); Budapest
- Country
- Hungary
- Manufacturer / Brand
- Mechanikai Laboratórium (ML); Budapest
- Year
- 1962–1968
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 137173
Original prospekt.
Original manual in 1965.
Original prospekt.
Click on the schematic thumbnail to request the schematic as a free document.
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Tape Recorder
- Power type and voltage
- Line / Batteries (any type) / 127; 220 / 6 ×1,5 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Reportermagnetofon R 5 - Mechanikai Laboratórium ML;
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 228 x 70 x 170 mm / 9 x 2.8 x 6.7 inch
- Net weight (2.2 lb = 1 kg)
- 2.4 kg / 5 lb 4.6 oz (5.286 lb)
- Author
- Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
