Riporter 6 R6b-K

• Country
• Hungary

• Manufacturer / Brand
• Mechanikai Laboratórium (ML); Budapest

• Year
• 1969–1973

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 170443

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 13

• Semiconductors
• AC107 AC107 AC107 OC1045 OC1045 OC1045 BC214 BC214 OC1045 OC1045 AC128 AC128 AC128 Z1,5 ZF6,2

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Batteries / addl. power jack / D: 6 × 1,5 / 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Metal case

• from Radiomuseum.org
• Model: Riporter 6 R6b-K - Mechanikai Laboratórium ML;

• Shape
• Portable set > 8 inch (also usable without mains)

• Notes

• Reportermagnetofon.

  Spulengrösse max. 10 cm.

• Source of data
• -- Schematic

• Literature/Schematics (1)
• Nagy Vilmos, A magyar orsósmagnó gyártás története

• Literature/Schematics (4)
• Rádiótechnika 1974/6.

• Author
• Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
