Koffer-Radio M395AB

• Country
• Switzerland

• Manufacturer / Brand
• Mediator; La Chaux-de-Fonds

• Year
• 1952/1953

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 12420

• Picture
• Schematics

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• DF91 DK92 DF91 DAF91 DL94

• Main principle
• Superhet with RF-stage; ZF/IF 452 kHz

• Power type and voltage
• Line / Batteries (any type)

• Loudspeaker
• Presumably Dynamic Loudspeaker (moving coil)

• from Radiomuseum.org
• Model: Koffer-Radio M395AB - Mediator; La Chaux-de-Fonds

• Notes
• In Unterlagen zum Kofferradio M395AB findet sich auch die Bezeichnung 395AB. Ganz allgemein kommt für Mediator die Bezeichnung mit oder ohne den Buchstaben M vor.

• Price in first year of sale
• 320.00 SFr

• External source of data
• E. Erb 3-907007-36-0

• Source of data
• Radiokatalog Band 2, Ernst Erb

• Other Models

• Here you find 371 models, 325 with images and 225 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
