MD6640T
Mediator; La Chaux-de-Fonds
- Country
- Switzerland
- Manufacturer / Brand
- Mediator; La Chaux-de-Fonds
- Year
- 1961/1962
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 12460
Gesamtansicht von oben / view from top
Vorderanscht / front view
Chassis Gesamtansicht / print general view
Chassis HF/ZF oben / print HF/IF top
Chassis HF/ZF unten / print HF/IF bottom
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 8
- Main principle
- Superhet with RF-stage; ZF/IF 452/6750 kHz
- Tuned circuits
- 6 AM circuit(s) 9 FM circuit(s)
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Power type and voltage
- Storage and/or dry batteries / 2 x 4.5 or 6 x 1.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: MD6640T - Mediator; La Chaux-de-Fonds
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 268 x 178 x 104 mm / 10.6 x 7 x 4.1 inch
- Notes
-
Das Gerät kann wahlweise mit 2 x 4.5 V Flachbatterien oder 6 x 1.5 V Batterien bestückt werden.
UKW-Bereich 88 - 100 MHz
Hergestellt durch Philips Deutschland, Apparatefabrik Wetzlar.
Siehe auch Georgette L3D02T mit weitgehend identischem Chassis.
- Net weight (2.2 lb = 1 kg)
- 2.2 kg / 4 lb 13.5 oz (4.846 lb)
- Price in first year of sale
- 238.00 SFr
- External source of data
- E. Erb 3-907007-36-0
- Source of data
- Radiokatalog Band 2, Ernst Erb
- Literature/Schematics (1)
- -- Original-techn. papers.
- Picture reference
- Das Modell ist im «Radiokatalog» (Erb) abgebildet.
- Other Models
-
Here you find 371 models, 325 with images and 225 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Mediator; La Chaux-de-Fonds
