MD8467A 16B
Mediator; La Chaux-de-Fonds
- Country
- Switzerland
- Manufacturer / Brand
- Mediator; La Chaux-de-Fonds
- Year
- 1964 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 196388
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 2
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Record Player (not changer)
- Power type and voltage
- Alternating Current supply (AC) / 110-220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: MD8467A 16B - Mediator; La Chaux-de-Fonds
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Notes
- 33, 45 und 78 U/min.
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Jörg Sigg. See "Data change" for further contributors.
