Lifetec 9 Band World Receiver LT7511
Medion; Essen
- Country
- Germany
- Manufacturer / Brand
- Medion; Essen
- Year
- 1994 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 316973
- Number of Transistors
- Semiconductors present.
- Semiconductors
- TDA2822M
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
- Power type and voltage
- Batteries / addl. power jack / AA: 2 x 1.5 / 3 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 cm = 2.2 inch
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Lifetec 9 Band World Receiver LT7511 - Medion; Essen
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 135 x 85 x 35 mm / 5.3 x 3.3 x 1.4 inch
- Notes
-
6x SW
- SW1 5.85 - 6.2 MHz
- SW2 7.1 - 7.5 MHz
- SW3 9.45 - 9.9 MHz
- SW4 11.5 - 11.95 MHz
- SW5 15.1 - 15.55 MHz
- SW6 17.45 - 18 MHz
- Net weight (2.2 lb = 1 kg)
- 0.265 kg / 0 lb 9.3 oz (0.584 lb)
- Author
- Model page created by Ottmar Lauth. See "Data change" for further contributors.
