• Country
• United States of America (USA)

• Manufacturer / Brand
• Meissner Mfg. Div., Maguire Industries, Inc. (IL)

• Year
• 1938–1943

• Category
• Commercial Receiver (may include amateur bands)

• Radiomuseum.org ID
• 265174

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 13

• Valves / Tubes
• 1853 6K8 6J7G 6K7 6J7G 6H6 6L7 6H6 6C8G 6C5 6V6 6V6 5V4G VR150

• Main principle
• Superhet with RF-stage; ZF/IF 456 kHz

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC)

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 8.5 W (undistorted)

• Material
• Metal case

• from Radiomuseum.org
• Model: Traffic Master - Meissner Mfg. Div., Maguire

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 19 x 14 x 10 inch / 483 x 356 x 254 mm

• Notes

• The Meissner Traffic Master covers 530 to 32,400 kHz in five bands. Includes S-meter, crystal filter and BFO. It was available as a kit with the tuning unit factory wired.

• Price in first year of sale
• 87.00 USD

• Mentioned in
• Communications Receivers (4th edition page 85.)

• Literature/Schematics (1)
• Cameradio Catalog 1940 page 162.

• Author
• Model page created by Wayne Childress. See "Data change" for further contributors.
