Model: PO20 - Meratronik SA; Warszawa

Shape
Tablemodel, with any shape - general.

Notes
Meratronik.

RC generator, type PO20.

Frequency range - 20Hz - 200kHz.

Author
Model page created by Wojtek Krzywicki. See "Data change" for further contributors.

Other Models
Here you find 26 models, 26 with images and 9 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
