• Country
• Germany

• Manufacturer / Brand
• Metrawatt, BBC Goerz Metrawatt, ABB Metrawatt; Nürnberg

• Year
• 1984 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 137800

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• Dry Batteries / 1 x 1,5 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Analoges Vielfachmessinstrument MA1H - Metrawatt, BBC Goerz Metrawatt

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 92 x 45 x 126 mm / 3.6 x 1.8 x 5 inch

• Notes
• Analoges Vielfachmessinstrument.
  Messbereich V DC 0.15 V bis 1000 V
  Messbereich V AC 1.5 V bis 500 V
  Messbereich A AC 2.5 mA bis 5 A.
  Messbereich A AD 0.05 mA bis 5 A.
  Im Ohmbereich sind 4 Messbereiche möglich.

• Net weight (2.2 lb = 1 kg)
• 0.250 kg / 0 lb 8.8 oz (0.551 lb)

• Price in first year of sale
• 99.00 DM

• External source of data
• FS 9/1985

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.
