Mecatron 6905

Metz Transformatoren- und Apparatefabrik (ex TAM), Fürth

Data
Forum
Pictures
Collections

  • Year
  • 1978 ??
  • Category
  • Miscellaneous (Other, Various) - see notes
  • Radiomuseum.org ID
  • 254341

 Technical Specifications

  • Number of Transistors
  • 2
  • Wave bands
  • - without
  • Details
  • Remote Control (with wire or wireless)
  • Power type and voltage
  • Dry Batteries / 1 x 9 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Mecatron 6905 - Metz Transformatoren- und
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 70 x 125 x 37 mm / 2.8 x 4.9 x 1.5 inch
  • Notes

  • Mecatron 6905
    U.a. für Metz Capri-Color 6942

    Infrarot-Fernbedienung
    16 Programmplätze

    Funktionen:

    • Lautstärke +/-
    • Helligkeit +/-
    • Kontrast +/-
    • Farbe +/-
    • Rückstellung auf Standart-Werte
    • "Tonstop" (Stummschaltung)
    • Gerät AUS

    Integrierte Schaltung: SAB3011
    Status LED
    3 Infrarot-LEDs



  • Author
  • Model page created by Daniel Burkei. See "Data change" for further contributors.
