teleclock 3 Rö.
Metz Transformatoren- und Apparatefabrik (ex TAM), Fürth
- Country
- Germany
- Manufacturer / Brand
- Metz Transformatoren- und Apparatefabrik (ex TAM), Fürth
- Year
- 1962/1963
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 24329
- Number of Tubes
- 3
- Number of Transistors
- 2
- Main principle
- Superheterodyne (common); ZF/IF 460/10700 kHz
- Tuned circuits
- 6 AM circuit(s) 9 FM circuit(s)
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Power type and voltage
- Line / Batteries (any type) / 110; 220 & für Uhr D: 1 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 4 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: teleclock [3 Rö.] - Metz Transformatoren- und
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 450 x 200 x 200 mm / 17.7 x 7.9 x 7.9 inch
- Notes
-
Eingebaute Präzisions-Schaltuhr mit automatischem elektrischem Aufzug (1,5-V-Monozelle).
Siehe auch Nachfolgemodell Metz Teleclock 153-R mit magischem Band.
- Net weight (2.2 lb = 1 kg)
- 4 kg / 8 lb 13 oz (8.811 lb)
- Price in first year of sale
- 349.00 DM
- External source of data
- Erb
- Source of data
- Handbuch VDRG 1962/1963
- Mentioned in
- Taxliste Franzis Verlag
