• Country
• Spain

• Manufacturer / Brand
• Micafix Electrónica; San Sebastián

• Year
• 1960/1961

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 150737

• • alternative name: Creig Electrónica

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 6

• Semiconductors
• OC44 OC45 OC45 OC71 OC72 OC72 unknown_diode

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Dry Batteries / 1 x 6 or 4 x 1.5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 0.75 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Picolin TR6 - Micafix Electrónica; San

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 153 x 87 x 37 mm / 6 x 3.4 x 1.5 inch

• Notes

• Puede usar bobinas de FI/RF de:

  • 4025 HUGUET
  • TR6 MICAFIX
  • 451 OLIVERAS

• Mentioned in
• -- Original prospect or advert

• Literature/Schematics (1)
• -- Schematic

• Literature/Schematics (2)
• Revista Española de Electrónica (REDE) nº 71 Octubre 1960

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
