• Country
• United States of America (USA)

• Manufacturer / Brand
• Midwest Radio Co., The, (Miraco); Cincinnati, OH

• Year
• 1948

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 47192

• • Brand: Miraco

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 16

• Valves / Tubes
• 6BA6 6BE6 6C4 7A7 6U5 7Q7 7A7 7A7 6AL5 7A4 7A6 7A4 7A4 7C5 7C5 5U4G

• Main principle
• Superhet with RF-stage; ZF/IF 456/10700 kHz

• Wave bands
• Broadcast, more than 2 SW bands plus FM or UHF.

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 105 - 125 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 11.5 inch = 29.2 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: 816 Ch= RGT-16 - Midwest Radio Co., The, Miraco

• Shape
• Console, Lowboy (legs < 50 %).

• External source of data
• Ernst Erb

• Circuit diagram reference
• Rider's Perpetual, Volume 18 = 1949 and before

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 45, Folder 16)

• Other Models

• Here you find 317 models, 181 with images and 214 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
