• Country
• Czechoslovakia

• Manufacturer / Brand
• Microphona (Mikrofona), Bratri Knotkove, Praha-Strasnice

• Year
• 1938–1940

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 23120

• • alternative name: Telefony Microfona

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 3

• Valves / Tubes
• Z63 KT66 U10

• Main principle
• TRF with regeneration; 1 AF stage(s)

• Tuned circuits
• 1 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• Permanent or electro-dynamic (moving coil), system not known yet.

• Material
• Bakelite case

• from Radiomuseum.org
• Model: Jubilant MK211 [var2] - Microphona Mikrofona, Bratri

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 340 x 334 x 230 mm / 13.4 x 13.1 x 9.1 inch

• Notes
• mit englischen Röhren bestückt - aber wirklich KT66?

• External source of data
• Erb

• Source of data
• Ceskoslovenske prijimace 1933-1945, Baudys 1947
