• Country
• Germany

• Manufacturer / Brand
• Militär (verschiedene Hersteller gleicher Modelle)

• Year
• 1940–1945

• Category
• Power supply/conditioner or battery or charger

• Radiomuseum.org ID
• 112478

• • alternative name: WEHRMACHT

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Umformersatz U 80a - Militär verschiedene

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 360 x 190 x 260 mm / 14.2 x 7.5 x 10.2 inch

• Notes

• Einanker-Umformer, erzeugt für den Wehrmachtssender 80 W.S.a die Anodenspannung von 800 V und die Gittervorspannung von -300 V.

• Net weight (2.2 lb = 1 kg)
• 30 kg / 66 lb 1.3 oz (66.079 lb)

• Mentioned in
• Die Deutschen Funknachrichtenanlagen, Bd.3

• Author
• Model page created by a member from A. See "Data change" for further contributors.
