Amplificatore RF 2 Metri Oscar 7

MILAG Elettronica Srl - Giovanni Lanzoni; Milano

Data
Forum
Pictures
Collections

  • Year
  • 1978 ??
  • Category
  • Amateur Equipment (Other, but not Key)
  • Radiomuseum.org ID
  • 341254

 Technical Specifications

  • Number of Tubes
  • 1
  • Main principle
  • Radio Frequency Amplification only
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC)
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Amplificatore RF 2 Metri Oscar 7 - MILAG Elettronica Srl -
  • Shape
  • Tablemodel, with any shape - general.
  • Notes

  • Amplificatore lineare per radiofrequenza operante nella gamma 144 MHz (VHF 2 metri), modi AM/FM/SSB.

    • Ingresso minimo 2,5 W per 250 W in uscita.
    • Ingresso massimo 15 W per 300 W in uscita.
    • Massima uscita in FM: 250 W eff.
    • Massima uscita in AM: 150 W eff.
    • Massima uscita in SSB: 300 W eff.
  • Mentioned in
  • -- Original prospect or advert (“Radio Rivista” organo ufficiale dell’ARI Italia, numero 5, maggio 1978.)
  • Literature/Schematics (1)
  • -- Original prospect or advert (Radio Elettronica Kit, CEC edizioni, Faenza. N. 0, febbraio 1978.)
  • Author
  • Model page created by Pier Antonio Aluffi. See "Data change" for further contributors.
