Receiver R-100/URR (Signal Corps Order No= 17558-Phila-45-03)
MILITARY U.S. (different makers for same model)
- Country
- United States of America (USA)
- Manufacturer / Brand
- MILITARY U.S. (different makers for same model)
- Year
- 1944–1946 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 107705
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superhet with RF-stage; ZF/IF 455 kHz; 3 AF stage(s)
- Tuned circuits
- 5 AM circuit(s)
- Wave bands
- Broadcast plus 2 Short Wave bands.
- Power type and voltage
- Line / Batteries (any type) / 12- / 90- / 110~ Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Metal case
- from Radiomuseum.org
- Model: Receiver R-100/URR - MILITARY U.S. different makers
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 427 x 287 x 230 mm / 16.8 x 11.3 x 9.1 inch
- Notes
-
Radio Receiver R-100/URR called the "Morale Builder", designed for entertaining and maintaining morale of troops. Reception of voice-modulated signals in the broadcast band 0.54-1.5 MHz and two HF bands 3.6-8.5 MHz and 8.5-19 MHz. Manufactured in the US by Zenith, Majestic and Espey. Many sets were made in Europe in 1945 and later.
- Net weight (2.2 lb = 1 kg)
- 8.5 kg / 18 lb 11.6 oz (18.722 lb)
- Source of data
- -- Collector info (Sammler)
- Mentioned in
- -- Original prospect or advert (TM 11-487A Directory of Signal Corps Equipments. Department of the Army, August 1950.)
- Author
- Model page created by Valery Gromov. See "Data change" for further contributors.
