R-392 {Р-392}
MILITARY USSR (different makers for same model)
- Country
- Soviet Union
- Manufacturer / Brand
- MILITARY USSR (different makers for same model)
- Year
- 1983 ?
- Category
- Military Transceiver (TRX)
- Radiomuseum.org ID
- 246834
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Transceiver; ZF/IF 13000/1600 kHz
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Storage and/or dry batteries / 12 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: R-392 {Р-392} - MILITARY USSR different makers
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 130 x 55 x 230 mm / 5.1 x 2.2 x 9.1 inch
- Notes
-
Tragbares Funksprechgerät, 6 Festfrequenzen im Bereich 44 - 50 MHz, Frequenzmodulation, Sender-Ausgangsleistung 1,6 W.
Betrieb mit Akkumulator 10NKGZ-1D.
Reichweite mit Kulikow-Antenne 10 km.
- Net weight (2.2 lb = 1 kg)
- 1.9 kg / 4 lb 3 oz (4.185 lb)
- Author
- Model page created by Siegfried Droese. See "Data change" for further contributors.
