- Country
- Soviet Union
- Manufacturer / Brand
- MILITARY USSR (different makers for same model)
- Year
- 1944–1947
- Category
- Military Transceiver (TRX)
- Radiomuseum.org ID
- 115209
RKK Radio Museum for RMorg
RKK Radio Museum for RMorg
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 11
- Main principle
- Transceiver; ZF/IF 1100 kHz
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Storage and/or dry batteries / 2,4 / 160 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Reid-I - MILITARY USSR different makers
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 210 x 385 x 330 mm / 8.3 x 15.2 x 13 inch
- Notes
-
Special modification of A-7-A FM transceiver used by Soviet Navy at their shore artillery locations. 27-32 MHz, phone (F3) and modulated CW (F2). Transmitter output around 1W.
- Net weight (2.2 lb = 1 kg)
- 15.5 kg / 34 lb 2.3 oz (34.141 lb)
- Source of data
- -- Schematic
- Mentioned in
- -- Collector info (Sammler)
- Author
- Model page created by Zenonas Langaitis. See "Data change" for further contributors.
