• Country
• Italy

• Manufacturer / Brand
• Minerva (Ital-Minerva); Milano

• Year
• 1943 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 194901

• • alternative name: Cozzi Luigi Dell'Aquila

• Number of Tubes
• 5

• Valves / Tubes
• ECH4 EF6 EBF2 6V6 AZ1

• Main principle
• Superheterodyne (common); ZF/IF 470 kHz

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 145; 160; 220; Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 21 cm = 8.3 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Unknown - Minerva Ital-Minerva; Milano

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 465 x 310 x 210 mm / 18.3 x 12.2 x 8.3 inch

• Source of data
• - - Data from my own collection

• Author
• Model page created by Stefano De Marchi. See "Data change" for further contributors.
