• Country
• Italy

• Manufacturer / Brand
• Minerva (Ital-Minerva); Milano

• Year
• 1955

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 306793

• • alternative name: Cozzi Luigi Dell'Aquila

• Number of Tubes
• 23

• Valves / Tubes
• ECC84 ECF80 EF80 EF80 EF80 EF80 EL83 EF80 EF80 EABC80 EL84 ECC82 ECF80 EB91 ECC82 EL81 EY81 DY86 ECC82 EL84 PY82 PY82 21EP4

• Main principle
• Superhet with RF-stage

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC)

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 2.5 W (undistorted)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 5553/1 - Minerva Ital-Minerva; Milano

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 630 x 570 x 580 mm / 24.8 x 22.4 x 22.8 inch

• Net weight (2.2 lb = 1 kg)
• 42 kg / 92 lb 8.2 oz (92.511 lb)

• Price in first year of sale
• 220,000.00 ITL

• Author
• Model page created by Alessandro De Poi. See "Data change" for further contributors.
