Kosmonavt {Космонавт}

Minsk Radio Works; Minsk

Data

Forum

Pictures

Collections

Country
Soviet Union

Manufacturer / Brand
Minsk Radio Works; Minsk

Year
1964

Category
Broadcast Receiver - or past WW2 Tuner

Radiomuseum.org ID
113833

- alternative name: Industrial Union Horizont || Minsk Works "Kalibr"

Schematics

Kosmonavt {Космонавт} ; Minsk Radio Works; (ID = 304734) Radio — Minsk Radio Works; Kosmonavt {Космонавт} (3)

Kosmonavt {Космонавт} ; Minsk Radio Works; (ID = 304735) Radio — Minsk Radio Works; Kosmonavt {Космонавт} (3)

Kosmonavt {Космонавт} ; Minsk Radio Works; (ID = 304736) Radio — Minsk Radio Works; Kosmonavt {Космонавт} (3)

Kosmonavt {Космонавт} ; Minsk Radio Works; (ID = 318141) Radio — Minsk Radio Works; Kosmonavt {Космонавт} (1)
Kaunas Lithuania

Kosmonavt {Космонавт} ; Minsk Radio Works; (ID = 318143) Radio — Minsk Radio Works; Kosmonavt {Космонавт} (1)
Kaunas Lithuania

Kosmonavt {Космонавт} ; Minsk Radio Works; (ID = 318144) Radio — Minsk Radio Works; Kosmonavt {Космонавт} (1)
Kaunas Lithuania

Kosmonavt {Космонавт} ; Minsk Radio Works; (ID = 304729) Radio — Minsk Radio Works; Kosmonavt {Космонавт} (2)

Kosmonavt {Космонавт} ; Minsk Radio Works; (ID = 304730) Radio — Minsk Radio Works; Kosmonavt {Космонавт} (2)

Kosmonavt {Космонавт} ; Minsk Radio Works; (ID = 304732) Radio — Minsk Radio Works; Kosmonavt {Космонавт} (2)

Kosmonavt {Космонавт} ; Minsk Radio Works; (ID = 318142) Radio — Minsk Radio Works; Kosmonavt {Космонавт} (1)
Kaunas Lithuania

Kosmonavt {Космонавт} ; Minsk Radio Works; (ID = 851527) Radio — Minsk Radio Works; Kosmonavt {Космонавт} (1)

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Transistors
8

Semiconductors
П422 П422 П422 П422 П15 П15 П15 П15

Main principle
Superheterodyne (common)

Wave bands
Broadcast (MW) and Long Wave.

Power type and voltage
Dry Batteries / 3 × 1,5 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

Power out
0.25 W (unknown quality)

Material
Plastics (no bakelite or catalin)

from Radiomuseum.org
Model: Kosmonavt {Космонавт} - Minsk Radio Works; Minsk

Shape
Design Radio or Novelty / Gadget - fancy or unusual shape.

Dimensions (WHD)
224 x 168 x 68 mm / 8.8 x 6.6 x 2.7 inch

Notes
Table - portable transistor radio set.

Author
Model page created by Zenonas Langaitis. See "Data change" for further contributors.
