6X-145

• Country
• Japan

• Manufacturer / Brand
• Mitsubishi Electric Corporation

• Year
• 1960 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 108290

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 6

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Dry Batteries / 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: 6X-145 - Mitsubishi Electric

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 2.37 x 3.75 x 1.25 inch / 60 x 95 x 32 mm

• Notes

• Made in Japan. Station thumb dial can be turned from the top or the side of the radio.  US Civil Defense marks on station plate.

• Mentioned in
• -- Collector info (Sammler)

• Literature/Schematics (1)
• Collector's Guide To TrR1 Bunis trans.94 (Model info and image on page 159-160)

• Literature/Schematics (2)
• Transistor Radios (Model info and image on page 66)

• Author
• Model page created by Peter Hoddow. See "Data change" for further contributors.
