• Country
• Japan

• Manufacturer / Brand
• Mitsubishi Electric Corporation

• Year
• 1959

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 108287

• Number of Transistors
• 6

• Semiconductors

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 5 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Dry Batteries / 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: 6 X-720 - Mitsubishi Electric

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 69 x 103 x 28 mm / 2.7 x 4.1 x 1.1 inch

• Notes

• Made in Japan. AM only (535 - 1605 kHz).  Easel stand in back.  External antenna jack.

• Literature/Schematics (1)
• Collector's Guide To TrR1 Bunis trans.94 (Model info on page 160)

• Author
• Model page created by Peter Hoddow. See "Data change" for further contributors.
