• Country
• Japan

• Manufacturer / Brand
• Mitsubishi Electric Corporation

• Year
• 1978 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 207914

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: AM FM Stereo Tuner DA-F680 - Mitsubishi Electric

• Shape
• Rack

• Dimensions (WHD)
• 480 x 162 x 410 mm / 18.9 x 6.4 x 16.1 inch

• Notes
• AM FM Stereo Tuner mit massiver geschliffener Alu Front und Echtglas Scheibe vor der Skala.

• Net weight (2.2 lb = 1 kg)
• 7.5 kg / 16 lb 8.3 oz (16.52 lb)

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
