• Country
• Japan

• Manufacturer / Brand
• Mitsubishi Electric Corporation

• Year
• 1978 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 211666

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superhet with RF-stage

• Wave bands
• FM Broadcast Band Only

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: FM Stereo Tuner M-F01 - Mitsubishi Electric

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 270 x 70 x 247 mm / 10.6 x 2.8 x 9.7 inch

• Notes
• UKW-Tuner. Manuelle Drehkondensator-Abstimmung mit 100Khz Raster, hohe Empfindlichkeit 1,2uV (26dB S/N)Mono.

• Net weight (2.2 lb = 1 kg)
• 3.2 kg / 7 lb 0.8 oz (7.048 lb)

• Source of data
• -- Original-techn. papers.
