VHS-Videorecorder HS-301E

Mitsubishi Electric Corporation

Data
Forum
Pictures
Collections

  • Year
  • 1980 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 246798

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Details
  • Video-Taperecorder/-Player
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 120; 220; 240 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: VHS-Videorecorder HS-301E - Mitsubishi Electric
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 498 x 162 x 346 mm / 19.6 x 6.4 x 13.6 inch
  • Notes

  • VHS-Videorecorder, Empfang E2-E12, E21-E69. Ausgang justierbarE34-E38.

    PAL-B,G.

  • Net weight (2.2 lb = 1 kg)
  • 15.1 kg / 33 lb 4.2 oz (33.26 lb)
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by a member from D. See "Data change" for further contributors.
