R55

Mivar (VAR); Milano

Data
Forum
Pictures
Collections

  • Year
  • 1975 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 332593

 Technical Specifications

  • Number of Transistors
  • 18
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: R55 - Mivar VAR; Milano
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 505 x 135 x 180 mm / 19.9 x 5.3 x 7.1 inch
  • Notes
    • 18 transistor + 1 CI
    • Consumo 40W
    • Stereo uscita 2 ap. 4Ω
    • nr 1 presa Tape (In/Out) + nr 1 presa Fono
    • FM stereo 87,5 - 105 MHz
    • Presa antenna OM ed OC separate, presa antenna FM bilanciata
  • Net weight (2.2 lb = 1 kg)
  • 4.650 kg / 10 lb 3.9 oz (10.242 lb)
  • Author
  • Model page created by Mario Banfi. See "Data change" for further contributors.
