• Country
• Germany

• Manufacturer / Brand
• Monacor, Bremen

• Year
• 1979 ?

• Category
• Miscellaneous (Other, Various) - see notes

• Radiomuseum.org ID
• 264454

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Echo/Hall-Gerät EEM-2000 - Monacor, Bremen

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 345 x 175 x 95 mm / 13.6 x 6.9 x 3.7 inch

• Notes

• Echo / Hall-Gerät mit Eimerkettenspeicher,

  20mSek. - 200mSek., kontiunierlich einstellbar,

  getrennte regelbare Eingänge für Mikro und Instrument.

• Net weight (2.2 lb = 1 kg)
• 2.5 kg / 5 lb 8.1 oz (5.507 lb)

• Mentioned in
• -- Original-techn. papers.

• Literature/Schematics (1)
• Funkschau (18/1979, S. 1068)

• Author
• Model page created by a member from D. See "Data change" for further contributors.
