• Country
• Germany

• Manufacturer / Brand
• Monacor, Bremen

• Year
• 1978 ??

• Category
• Microphone or Pick-up element

• Radiomuseum.org ID
• 167520

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• Dry Batteries / 1,5 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: ECM-200 - Monacor, Bremen

• Shape
• Miscellaneous shapes - described under notes.

• Dimensions (WHD)
• 75 x 200 x 110 mm / 3 x 7.9 x 4.3 inch

• Notes
• Electret Kondensator Mikrofon. Impedanz 600 Ohm. Tischmikrofon mit Druckschalter.

• Net weight (2.2 lb = 1 kg)
• 0.280 kg / 0 lb 9.9 oz (0.617 lb)

• Author
• Model page created by Peter Böhm. See "Data change" for further contributors.
