• Country
• Germany

• Manufacturer / Brand
• Monacor, Bremen

• Year
• 1978 ??

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 133547

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 33

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Metal case

• from Radiomuseum.org
• Model: Power Amplifier HPB-220 - Monacor, Bremen

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 240 x 180 x 70 mm / 9.4 x 7.1 x 2.8 inch

• Notes
• HPB-220 Monacor is a power amplifier for car. It can drive 4 discrete outputs. His power supply is pulse digital regulated. Power 120 watts + 120 watts stereo

• Net weight (2.2 lb = 1 kg)
• 2.8 kg / 6 lb 2.7 oz (6.167 lb)

• Source of data
• -- Original prospect or advert

• Author
• Model page created by Jacky Parmentier. See "Data change" for further contributors.
