• Country
• Germany

• Manufacturer / Brand
• Monacor, Bremen

• Year
• 1990 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 208276

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• from Radiomuseum.org
• Model: Signal Generator/Counter SGD-2000 - Monacor, Bremen

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 220 x 110 x 210 mm / 8.7 x 4.3 x 8.3 inch

• Notes
• Monacor Signal Generator/Counter SGD-2000;
  Generator 100 kHz - 150 MHz in 6 Bereichen (450 MHz mit 3. Oberwelle).
  Audio-Output 1 kHz.
  Frequency Counter, 6-stellig, 10 Hz bis 150 MHz Torzeit 0.1 sec oder 1 sec.
  Quarztester 1 - 15 MHz über an der Frontplatte befindliche Quarz-Fassung.

• Author
• Model page created by a member from A. See "Data change" for further contributors.
