• Country
• Germany

• Manufacturer / Brand
• Monacor, Bremen

• Year
• 1975–1979 ??

• Category
• Amateur Equipment (Other, but not Key)

• Radiomuseum.org ID
• 78860

Click on the schematic thumbnail to request the schematic as a free document.

• Main principle
• Crystal or Solid State Detector

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• No Power needed

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Stehwellenmessbrücke FSI-2 - Monacor, Bremen

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 80 x 50 x 40 mm / 3.1 x 2 x 1.6 inch

• Notes
• Stehwellenmeßgerät (Richtkopplerprinzip) für den Bereich 3,5 bis 30 MHz, besonders empfindlich, daher oft auch für 11-Meter-Anwendungen benutzt. Impedanz 52 Ohm, Anschlüsse SO-239 (UHF). In Japan hergestellt.

• Net weight (2.2 lb = 1 kg)
• 0.6 kg / 1 lb 5.1 oz (1.322 lb)

• Source of data
• Radiokatalog Band 2, Ernst Erb

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by a member from D. See "Data change" for further contributors.
