Stehwellenmessbrücke FSI-9
Monacor, Bremen
- Country
- Germany
- Manufacturer / Brand
- Monacor, Bremen
- Year
- 1976 ??
- Category
- Amateur Equipment (Other, but not Key)
- Radiomuseum.org ID
- 186649
Hannes Bauer-Katalog, 1976
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Wave bands
- - without
- Power type and voltage
- No Power needed
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Stehwellenmessbrücke FSI-9 - Monacor, Bremen
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 170 x 55 x 105 mm / 6.7 x 2.2 x 4.1 inch
- Notes
- Monacor Stehwellenmessbrücke FSI-9.
Frequenzbereiche: 27–30, 50, 144 MHz; Impedanz: 52 Ohm; Belastbarkeit: 10 W, 100 W; SWR: 1:1–1:3; Instrument: 100 µA; Ausgerüstet mit Autohalterung.
- Price in first year of sale
- 140.00 DM
- Source of data
- -- Original prospect or advert
- Mentioned in
- Hannes Bauer-Katalog, 1976
- Author
- Model page created by Bernd P. Kieck. See "Data change" for further contributors.
