Stereo Equalizer Mischpult MPX-8000 C
Monacor, Bremen
- Country
- Germany
- Manufacturer / Brand
- Monacor, Bremen
- Year
- 1985 ??
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 216773
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 20
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Stereo Equalizer Mischpult MPX-8000 C - Monacor, Bremen
- Dimensions (WHD)
- 360 x 75 x 260 mm / 14.2 x 3 x 10.2 inch
- Notes
- Stereo Equalizer Mischpult MPX-8000 C
Eingänge: 2× Phono/Line (umschaltbar), 2× Mikro. Eingebauter Entzerrervorverstärker, 5-Band-Grafikequalizer, Fader, Monitoranschluss.
- Source of data
- -- Original-techn. papers.
- Author
- Model page created by a member from D. See "Data change" for further contributors.
