Stereo-Graphic-Equalizer GE-206
Monacor, Bremen
- Country
- Germany
- Manufacturer / Brand
- Monacor, Bremen
- Year
- 1980 ?
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 126993
Funkschau 3.1980
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 2
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Stereo-Graphic-Equalizer GE-206 - Monacor, Bremen
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 446 x 65 x 180 mm / 17.6 x 2.6 x 7.1 inch
- Notes
- 2 x 10 Klangregler, Frequenzbereich 5 bis 10 000 Hz, Klirrfaktor 0,05% bei 0,775 V (0 dB) Ausgang.
- Mentioned in
- Funkschau (3.1980)
- Author
- Model page created by Karlheinz Fischer. See "Data change" for further contributors.
