- Country
- Germany
- Manufacturer / Brand
- Monette, Mock & Nettebeck; Berlin
- Year
- 1926/1927
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 15969
Werbung von 1926
- Number of Tubes
- 3
- Main principle
- TRF with regeneration; 2 AF stage(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Storage and/or dry batteries
- Loudspeaker
- - For headphones or amp.
- Material
- Wooden case, TUBES VISIBLE.
- from Radiomuseum.org
- Model: AW - Monette, Mock & Nettebeck;
- Shape
- Tablemodel, slant panel.
- Dimensions (WHD)
- 215 x 290 x 140 mm / 8.5 x 11.4 x 5.5 inch
- Notes
- RM 133,- mit allem!
- Price in first year of sale
- 60.00 RM
- External source of data
- E. Erb 3-907007-36-0
- Source of data
- Vox-Haus, Katalog 1926/1927 / Radiokatalog Band 2, Ernst Erb
- Circuit diagram reference
- Röhren in FS-Bestückungstabellen
