Airline 54KP-1209B Order= 62 C 1409 Y
Montgomery Ward & Co. (Wards, Airline); Chicago, IL
- Country
- United States of America (USA)
- Manufacturer / Brand
- Montgomery Ward & Co. (Wards, Airline); Chicago, IL
- Year
- 1945–1948
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 47764
-
- Brand: Airline or Air-Line
Sams Photofact Folders
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Storage and/or dry batteries / 1.5 & 90 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
- Power out
- 0.15 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Airline 54KP-1209B Order= 62 C 1409 Y - Montgomery Ward & Co. Wards,
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 17.75 x 9.25 x 8.5 inch / 451 x 235 x 216 mm
- Notes
- Photofact see under Trade name: Airline. SAMS Photofact, date 11-46, set 8, folder 468-15 features the Airline models 54KP-1209A and 54KP-1209B as the same schematic.
- Price in first year of sale
- 42.95 $
- External source of data
- Ernst Erb
- Source of data
- Collector's Guide to Antique Radios 4. Edition
- Circuit diagram reference
- Rider's Perpetual, Volume 16 = ca. 1948 and before
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 8, Folder 468-15)
- Literature/Schematics (2)
- Montgomery Ward Catalogs (Wards, Airline) (Spring/Summer 1947, page 670. Fall/Winter 1947/48, page 861.)
