Airline 62-133 Order= 162 B 133
Montgomery Ward & Co. (Wards, Airline); Chicago, IL
- Country
- United States of America (USA)
- Manufacturer / Brand
- Montgomery Ward & Co. (Wards, Airline); Chicago, IL
- Year
- 1934/1935
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 47806
-
- Brand: Airline or Air-Line
W.W.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Main principle
- Superhet with RF-stage; ZF/IF 456 kHz
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Alternating Current supply (AC) / 110 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: Airline 62-133 Order= 162 B 133 - Montgomery Ward & Co. Wards,
- Shape
- Console with any shape - in general
- Dimensions (WHD)
- 20.75 x 36 x 11 inch / 527 x 914 x 279 mm
- Notes
-
Chassis was available as 25 or 60-cycle or with an optional 110/220-volt 40/60-cycle power transformer. Broadcast Band: 530 to 1740kc and Shortwave Band: 5.8 to 18.3mc.
- Price in first year of sale
- 39.95 $
- External source of data
- Ernst Erb
- Source of data
- The Radio Collector's Directory and Price Guide 1921 - 1965
- Circuit diagram reference
- Rider's Perpetual, Volume 10 = 1939 and before
- Mentioned in
- Pre-War Consoles
- Literature/Schematics (3)
- Montgomery Ward Catalogs (Wards, Airline) (Fall and Winter 1934/35 page 319)
