• Country
• United States of America (USA)

• Manufacturer / Brand
• Montgomery Ward & Co. (Wards, Airline); Chicago, IL

• Year
• 1948 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 48388

• • Brand: Airline or Air-Line

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• 6BA6 12AT7 6BA6 6BA6 6AL5 6AT6 6AQ5 5Y3

• Main principle
• Superheterodyne (common); ZF/IF 455/10700 kHz

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 105 - 125 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm

• Power out
• 2 W (unknown quality)

• from Radiomuseum.org
• Model: 84BR-2726B - Montgomery Ward & Co. Wards,

• External source of data
• Ernst Erb

• Circuit diagram reference
• Rider's Perpetual, Volume 20 covering 1950

• Other Models

• Here you find 2290 models, 1459 with images and 1786 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Montgomery Ward & Co. (Wards, Airline); Chicago, IL
