- Country
- United States of America (USA)
- Manufacturer / Brand
- Montgomery Ward & Co. (Wards, Airline); Chicago, IL
- Year
- 1949
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 48551
-
- Brand: Airline or Air-Line
Beitman
Rider
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Line / Batteries (any type) / AC/DC 105-125 / 90 & 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.25 inch = 13.3 cm
- Power out
- 0.12 W (unknown quality)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: 94WG-1059A - Montgomery Ward & Co. Wards,
- Shape
- Portable set > 8 inch (also usable without mains)
- Notes
- Selenium Rectifier . Leatherette, lift-open lid.
- External source of data
- Ernst Erb
- Source of data
- Collector's Guide to Antique Radios 4. Edition
- Circuit diagram reference
- Rider's Perpetual, Volume 20 covering 1950
- Mentioned in
- The Radio Collector's Directory and Price Guide 1921 - 1965 (Collector's Guide to AR7.Ed. Slusser tube)
- Literature/Schematics (1)
- Beitman Radio Diagrams, Vol. 10, 1950
