Airline 04WG-2673A Order= P362 B 2673

Montgomery Ward & Co. (Wards, Airline); Chicago, IL

Data
Forum
Pictures
Collections

  • Year
  • 1940/1941
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 238437
    • Brand: Airline or Air-Line

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 456 kHz
  • Wave bands
  • Broadcast and Short Wave (SW).
  • Power type and voltage
  • Line / Batteries (any type) / Either AC: 50-60 cycles, 105-125V or Batteries: 9 & 90 Volt
  • Loudspeaker
  • Permanent or electro-dynamic (moving coil), system not known yet. / Ø 6 inch = 15.2 cm
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Airline 04WG-2673A Order= P362 B 2673 - Montgomery Ward & Co. Wards,
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 22.5 x 12.25 x 10.5 inch / 572 x 311 x 267 mm
  • Notes

  • The Montgomery Ward Airline 04WG-2673A is an AC/Battery operated 6 tube BC and SW receiver.

    The frequency tuning range is as follows:
    Broadcast Band (B Range)...................528 - 1600KHz
    Shortwave Band (D Range)...................5.75 - 18.3MHz

    This model was built for Montgomery Ward by the Wells Gardner Co, Chicago, ILL.

    NOTE: Starting in 1939, Montgomery Ward began adding the production series in the model number, with the letter "A" in the model number indicating the first production series.  Other service documentation (such as Riders) did not consistantly use the "A" in the model number when referring to the first production series models. However models without the "A" at the end of the model number are the same as the models with the "A".

  • Price in first year of sale
  • 30.95 $
  • Author
  • Model page created by Noemi Erb. See "Data change" for further contributors.
