Airline Seven
Montgomery Ward & Co. (Wards, Airline); Chicago, IL
- Country
- United States of America (USA)
- Manufacturer / Brand
- Montgomery Ward & Co. (Wards, Airline); Chicago, IL
- Year
- 1929 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 356892
-
- Brand: Airline or Air-Line
- Number of Tubes
- 7
- Main principle
- TRF without regeneration
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Storage and/or dry batteries / A +2 & B +22.5 & B +67 & B +90 & B +135 & C -4.5 & C -9 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Wooden case
- from Radiomuseum.org
- Model: Airline Seven - Montgomery Ward & Co. Wards,
- Shape
- Tablemodel, slant panel.
- Dimensions (WHD)
- 27.5 x 13.5 x 15 inch / 699 x 343 x 381 mm
- Notes
-
Two stage TRF tuners.
Tubes listed were likely the original tube complement. Later tube alternates were 230, 230, 230, 230, 230, 230, and 231 as found in at least one radio.
- Author
- Model page created by George Reisdorf. See "Data change" for further contributors.
