Airline WG-5102A

• Country
• United States of America (USA)

• Manufacturer / Brand
• Montgomery Ward & Co. (Wards, Airline); Chicago, IL

• Year
• 1955 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 331612

• • Brand: Airline or Air-Line

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 24

• Valves / Tubes
• 6AF4 6BZ7 6U8 6CB6 6CB6 6CB6 6AL5 12AT7 12BY7 6AU6 6AU6 6AU6 6AL5 6AV6 6AQ5 6CS6 6SN7GTA 6AL5 6SN7GTA 6CU6 6AX4GT 1B3GT 5U4GA 21ZP4B

• Main principle
• Superhet with RF-stage

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 inch = 25.4 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: Airline WG-5102A - Montgomery Ward & Co. Wards,

• Shape
• Console, Lowboy (legs < 50 %).

• Notes

• Airline model WG-5102A a 21” b/w TV with US standard VHF tuner channels 2 thru
  13, and 14 thru 83 UHF. Equipped with VHF- UHF- tuner 25A1128 and picture tube 21ZP4B.



• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 299 Folder 2 dated 12-55)

• Author
• Model page created by Dirk Taekels. See "Data change" for further contributors.

• Other Models

• Here you find 2291 models, 1459 with images and 1788 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Montgomery Ward & Co. (Wards, Airline); Chicago, IL
