• Country
• United States of America (USA)

• Manufacturer / Brand
• Montgomery Ward & Co. (Wards, Airline); Chicago, IL

• Year
• 1966/1967 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 296621

• • Brand: Airline or Air-Line

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 21

• Semiconductors
• 2N3392 2N3392 2N3392 2N3392 2N2953 2N2953 DTG-110 DTG-110 DTG-110 DTG-110 2N3588 2N3588 2N3588 2N3588 2N3592 2N3592 2N3592 2N3592 2N990 2N990 2N990

• Main principle
• Superhet with RF-stage; ZF/IF 455/10700 kHz

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz, 117 Volt

• Loudspeaker
• 6 Loudspeakers

• Power out
• 10 W (undistorted)

• Material
• Wooden case

• from Radiomuseum.org
• Model: GAA-2940 Ch= 7002 - Montgomery Ward & Co. Wards,

• Shape
• Console with any shape - in general

• Literature/Schematics (1)
• - - Manufacturers Literature

• Literature/Schematics (2)
• Photofact Folder, Howard W. SAMS (Sams Photofact Set 865, Folder 5)

• Author
• Model page created by Matthew Wilson. See "Data change" for further contributors.
