• Country
• United States of America (USA)

• Manufacturer / Brand
• Montgomery Ward & Co. (Wards, Airline); Chicago, IL

• Year
• 1956 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 284290

• • Brand: Airline or Air-Line

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 16

• Valves / Tubes
• 4BQ7A 5AT8 3CB6 3CB6 3CB6 12BY7A 5U8 3BN6 5AQ5 7AU7 12W6GT 6SN7GTA 12BQ6GA 12AX4GTA 1B3GT 21ATP4

• Main principle
• Superhet with RF-stage

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 60 cycles, 117V = 110 -120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Airline WG-4011A Code 21A59CT - Montgomery Ward & Co. Wards,

• Shape
• Tablemodel, with any shape - general.

• Notes

• The AIRLINE model WG-4011A Code 21A59CT is a 21" b/w TV with US standard VHF Tuner channels 2 thru 13. Equipped with VHF tuner 25A1133,  picture tube 21ATP4 and 2 selenium rectifiers

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 313 Folder 2 Dated 1956)

• Literature/Schematics (2)
• Photofact Folder, Howard W. SAMS (Set 340 Folder 1 Dated 12-56)

• Author
• Model page created by Dirk Taekels. See "Data change" for further contributors.
