• Country
• Soviet Union

• Manufacturer / Brand
• MEMZA Electromechanical Works (ex VTU), Moscow

• Year
• 1932–1938

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 90798

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• СО-124 СО-118 СО-118 УО-104 ВО-116

• Main principle
• TRF with regeneration

• Tuned circuits
• 3 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110/220 Volt

• Loudspeaker
• - For headphones or amp.

• Power out
• 0.8 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: ÈČS-2 {ЭЧС-2} - MEMZA Electromechanical Works

• Shape
• Tablemodel, Box - most often with Lid (NOT slant panel).

• Notes
• First alternating current supply Radio set in Soviet Union.
  Coverage 200-2000 meters in 4 ranges.
  Generally set used with separate loudspeaker "Rekord".

• Source of data
• -- Schematic

• Mentioned in
• -- Collector info (Sammler)

• Author
• Model page created by Zenonas Langaitis. See "Data change" for further contributors.
